Pixfra Mile 3 M625 Thermal Imaging Monocular - 640×512, 12µm, 25mm, <15mK NETD

The Pixfra Mile 3 M625 Thermal Imaging Monocular combines advanced thermal imaging performance with a compact, lightweight design weighing just 290g. Featuring a 640×512, 12µm thermal sensor and <15mK NETD sensitivity, it can detect heat sources at distances of up to 1300m while maintaining detailed thermal imagery in challenging conditions.

Powered by PIPS 3.0 Pro image processing, the Mile 3 enhances fine detail, reduces image noise and improves detector responsiveness, providing a clear thermal image across its magnification range. The 25mm f0.9 objective lens offers a 30.6 × 24.4m field of view at 100m, while 1.2–9.6x magnification and 8x digital zoom provide flexibility when observing subjects at different distances.

An industry-first 3-in-1 integrated e-wheel makes the Mile 3 easy to operate with one hand, providing control over digital focus, zoom and menu functions. The large 0.49" 1920×1080 OLED display provides a high-resolution viewing experience, while six colour palettes allow the thermal image to be adapted to different conditions.

The Mile 3 M625 also features built-in video and still image recording, Wi-Fi connectivity and 64GB of internal storage. Supplied with two rechargeable 18650 batteries, it provides up to 10 hours of combined observation time, making it well suited to wildlife observation, ecological surveys and outdoor exploration.

Advanced Thermal Imaging – The 640×512, 12µm thermal sensor provides detailed thermal imagery and can detect heat sources at distances of up to 1300m.
High Thermal Sensitivity – <15mK NETD sensitivity helps reveal subtle differences in temperature in fog, rain, humidity and other challenging conditions.
PIPS 3.0 Pro Processing – Pixfra's image processing system enhances fine detail, minimises noise and improves detector responsiveness, particularly in colder conditions.
Flexible Magnification – The 1.2–9.6x magnification range provides flexibility for observing subjects at varying distances.
8x Digital Zoom – Enables closer inspection of subjects when additional magnification is required.
Wide Field of View – The 25mm f0.9 objective lens provides a broad field of view for observation at 100m.
Six Colour Palettes – Choose between six different colour palettes to suit changing environmental conditions and observation preferences.
Enhanced Subject Identification – Sepia and Green Hot modes are designed to highlight subjects in red, helping create greater visual separation and depth.
One-Handed Operation – The integrated 3-in-1 e-wheel allows key functions to be controlled without needing to use both hands.
Digital Focus – Focus can be adjusted directly from the integrated control wheel rather than using an external objective focus mechanism.
Intuitive Zoom Control – A single press of the e-wheel allows users to move through the available magnification range.
Integrated Menu Control – A long press opens the menu, with the e-wheel providing navigation and selection.
Rubberised Bodyshell – Embossed X markings on the grip and dioptre control provide a secure hold and easier operation in wet conditions.
Inward-Rotating Dioptre Wheel – The recessed design helps reduce the risk of accidentally knocking the dioptre out of adjustment.
Slimline Construction – Digital focus control removes the need for an external focus mechanism on the objective lens, helping maintain the compact profile.
Long Battery Life – Two rechargeable 18650 batteries can be quickly exchanged, providing up to 10 hours of combined operation.
Built-in Video Recording – Record video with audio directly to the monocular's internal storage for later review.
Still Image Capture – Capture photographs directly through the thermal imaging system.
Built-in Wi-Fi – Connect the Mile 3 to the Pixfra app for additional viewing and control functions.
Second-Screen Functionality – Use a connected smartphone as a second display, useful for surveys and group observation.
Remote Control – Access and adjust settings through the connected Pixfra app without directly operating the monocular.
Multi-Device Connectivity – Connect up to four smart devices simultaneously for group observations.
64GB Internal Memory – Increased storage provides capacity for up to 25 hours of video or 150,000 photographs.
Hot Spot Tracking – Helps identify and follow areas of interest within the thermal image.
Picture-in-Picture – Provides an additional magnified view while retaining the wider thermal image.
Flexible FFC Calibration – Automatic, semi-automatic and manual calibration options are available.
Additional Observation Tools – Features include a compass, standby mode, defective pixel correction and local album functionality.
IP67 Protection – Designed to provide protection against dust and water for reliable outdoor use.
Wide Operating Temperature – Suitable for use in temperatures ranging from -30°C to +55°C.

Thermal Sensor: 640×512, 12µm
Thermal Sensitivity: <15mK NETD
Objective Lens: 25mm f0.9
FOV @ 100m: 30.6 × 24.4m
Focus Control: Manual
Close Focus Distance: 1m (3.28ft)
Detection Range: 1300m
Magnification Range: 1.2–9.6x
Digital Zoom: 8x
Display: 1920×1080, 0.49" OLED
Colour Palettes: 6
Dioptre: -5 D to +3 D
Eye Relief: 15mm
Video Recorder: Yes, with audio
Still Image Capture: Yes
Wi-Fi: Yes
Hot Spot Track: Yes
FFC Calibration: Auto, Semi-Auto, Manual
Standby Mode: Yes
Defective Pixel Correction: Yes
Compass: Yes
Picture-in-Picture: Yes
Local Album: Yes
Storage: Built-in, 64GB
Battery Type: 18650 ×2 provided
Battery Life: Up to 5 hours at 25°C, Wi-Fi off
Power Supply: 5 VDC
USB: USB Type-C
Operating Temperature: -30 to +55°C
Operating Humidity: 95%
Protection Grade: IP67
Dimensions (H × W × D): 160 × 52.6 × 50.5mm
Weight: 290g

Pixfra Mile 3 M625 Thermal Imaging Monocular

Pixfra 3 year warranty
