HIKMICRO Lynx LH19 3.0 19mm Thermal Monocular - <18mK 320x240px 12µm 50Hz

The HIKMICRO Lynx LH19 3.0 is a compact, high-performance thermal monocular designed for professionals who require reliable imaging, smooth operation, and excellent portability. Ideal for security teams, marine use, search and rescue, and outdoor applications, it combines advanced thermal sensitivity with intelligent processing for consistently clear results.

Powered by a 384×288 thermal detector and a bright 19mm F1.0 lens, the LH19 offers 1.9× base magnification, a wide 13.8° field of view, and an effective 900-metre detection range. Its AI-enhanced Image Pro 3.0 and Zoom Pro algorithms deliver improved contrast, detail, and stability, while the HSIS shutterless system provides silent, uninterrupted viewing.

Built for demanding environments, the LH19 weighs just 331g and uses a replaceable 18650 battery providing up to 4.5 hours of operation even at –20°C. Compact, durable, and engineered for precision, it is the ideal choice for users needing professional-grade thermal performance in a lightweight form.

- Improved Thermal Sensitivity: Powered by a <18mK VOx sensor for enhanced contrast and detail in challenging conditions.
- Optimised Medium-Range Lens: The 19mm F1.0 lens provides a balance of reach and field of view, suitable for scanning wide areas or pinpointing heat sources.
- AI Image Processing: Image Pro 3.0 enhances clarity and sharpness, while Zoom Pro ensures smoother digital zoom operation.
- Shutterless Visual Experience: HSIS technology eliminates calibration pauses and mechanical noise for uninterrupted monitoring.
- High-Quality Display: A 1920×1080 AMOLED screen delivers excellent colour, brightness, and clarity for extended viewing sessions.
- Ergonomic, Lightweight Build: Compact design at 331g contributes to fatigue-free use during prolonged operations.
- Durable Construction: IP67-rated for protection against water, dust, and harsh outdoor conditions.

Image Sensor: VOx Uncooled Focal Plane Arrays
Max Resolution: 384 × 288
Frame Rate: 50 Hz
Pixel Interval: 12 μm
NETD: <18 mK (@25°C), F#=1.0
Lens: 19 mm, F1.0
Focus Mode: Focus Wheel
Min. Focusing Distance: 3 m
Magnification: 1.9× – 15.2× (8×)
Field of View: 13.8° × 8.4° / 24.2 m × 14.7 m @100 m
Detection Range: 900 m
Display: 1920 × 1080, 0.49-inch AMOLED
Palettes: Black Hot, White Hot, Red Hot, Fusion, Red Monochrome, Green Monochrome
Eye Relief: 20 mm
Dioptre Adjustment: -5D to +3D
Tone Adjustment: Cold, Warm
Battery Type: Replaceable 18650 rechargeable battery
Protection Level: IP67
Weight: 331 g (with battery)

1 x Lynx 3.0 Thermal Monocular
1 x Quick Start Guide
2 x 18650 Battery
1 x Type-C USB Cable
1 x Battery Charger
1 x Lint Free Cloth

3 Year Warranty

HIKMICRO has a full UK service and technical centre, complete with Hotline: 0203 514 0092 available to assist with any issues.
