HIKMICRO Raptor RQ50L 640x512 12um 20mK 50mm F0.9 Thermal Fusion Optical IR LRF Binoculars

The detail of the thermal image you see on the screen is defined by the quality of the components and their ability to measure small differences in temperature. The HIKMICRO Raptor Pro RQ50L is equipped with HIKMICRO’s all new SUB 20 NETD 640x512px sensor, this is the most accurate available on the market today. Another first is the F0.9 aperture 50mm lens system which offers an unrivalled ability to transmit the thermal signal, ensuring that more of the detail reaches the sensor. These key components combine to deliver highly detailed thermal images and the best performance in adverse weather conditions.

The HIKMICRO Raptor Pro RQ50L also has a high-quality day & night optical camera built in. During daylight hours you can call on a detailed full-colour image to help identify the heat source you have located. When it gets dark the camera switches to night mode and the inbuilt IR will help you to see up to 400m in the dark. The inbuilt image stabilisation reduces handshake and allows you to use the Raptor like a conventional set of binoculars and get a clear image even at high magnification.

The final lens on the front of the HIKMICRO Raptor Pro RQ50L belongs to the Integrated Laser Range Finder. This can measure distances of targets up to 1000m away and is accurate to ±1m. The HIKMICRO Raptor Pro RQ50L also has a compass and GPS built in for detailed location information.

The ergonomic chassis of the The HIKMICRO Raptor Pro RQ50L is comfortable for use over a long period and allows all of the major controls to fall easily to hand. The focus for the thermal image is located on the bridge of the binoculars, between the eyepieces while each button falls comfortably to a finger and is intuitive to use, even in the dark. The Raptor is powered by 3x 18650 batteries to give a run time of 8 hours and the detachable battery compartment makes it easy to change.

The dual eyepieces of the HIKMICRO Raptor Pro RQ50L deliver information to both eyes at the same time which aids detection and is more comfortable for use over a long period. The Raptor can be adjusted to comfortably fit your eyes with the interpupillary distance being adjusted from 60mm to 70mm giving you an excellent view of the HD OLED display. The inbuilt sensor can tell when you take the binoculars away from your face and automatically switches the displays off to eliminate any light spill that may illuminate you in the dark.

20mK high-sensitivity thermal camera
1000m Laser Rangefinder
2560x1440 HD Day & Night Camera
Automatic display on & off - avoid light leakage from the eyepiece
Groundbreaking and humanized design - designed by the Red Dot award-winning designer intuitive operation
Up to 2600m detection range
SIGHT App connection
Multiple image modes

MAIN
Sensor: 640x512px @ 12µm
Objective Lens (Focal Length): 50 mm
Detection Distance: 2600 m

SENSOR
Type: VOx Uncooled Focal, Plane Arrays
Resolution, pixels: 640x512 PX
Pixel pitch, µm: 12µm
Frame rate, Hz: 25 Hz
NETD: <20mK

THERMAL OPTICS
Objective lens: F0.9
Magnification (Optical): 3.4x
Magnification (Digital): 1x, 2x, 4x, 8x
Min. Focusing Distance: 5m
Field of view:  8.8° × 7° (H × V)°

OPTICAL CAMERA
Image Sensor:  Progressive Scan CMOS
Resolution: 2560 x 1440px
Focal Length: 31mm
Aperture: F1.2
Image Stabilisation: Yes
Smart IR: Yes
IR Wavelength: 850nm
Viewing range in darkness: 400m

LASER RANGE FINDER
Max Measuring range: 1000m
Safety Class for laser: Class 1
Measurement accuracy: ± 1m

DISPLAY
Type: 10mm, OLED
Resolution, Pixels:  1024 x 768
Thermal Colour Palettes: Image Fusion, Black Hot, White Hot, Red Hot, Fusion
Optical Colour Palettes: Day, Night, Auto, Defog

VIDEO RECORDER
Build in memory, Gb: 64 Gb
Image Capture: 1600 x 1200px JPG
Video Record: 1600 x 1200px MP4
Audio recording: Yes

ADDITIONAL FEATURES
Automatic Standby: YES
GPS & Compass: YES
Image Pro Mode: YES
Hot Tracking:  YES
WiFI hot spot: YES
HIKMICRO Connect App support: YES

ENVIRONMENTAL
Degree of protection, IP code: IP67
Dust protection: Protected against dust ingress
Water protection: Protected against temporary submersion in water
Operating temperature range: -30 °C to 55 °C

WEIGHT & SIZE
Dimensions, mm: 217 mm x 155 mm x 87 mm
Interpupillary Adj.: 60mm to 70mm
Weight, kg: 1120 g

POWER SUPPLY
Battery type: 3x 18650 Removable battery
Operating time on battery (WiFi & Hot tracking disabled): 8 Hours continuous running
Compatible with USB Powerbank: YES
Charging interface: External charger (Supplied)

Warranty Period
Main Unit: 3 Years

HIKMICRO HM-RQ50L Raptor 640px 50mm LRF Thermal Binoculars
Battery charger
2x 18650 batteries

3 year warranty
